Automatic Stainless Steel Chemical PAM/PAC Flocculant Dosing and Mixing Machine for Industrial Wastewater Treatment
Quick Detail:
Automatic Chemical Dosing System
various stages of wastewater treatment
- Overview
- Recommended Products
| Place of Origin: | Shandong,China |
| Brand Name: | Jinwantong |
| Model Number: | JWT-ADS |
| Certification: | CE/ISO |
| Minimum Order Quantity: | 1SET |
| Delivery Time: | 20days |
| Payment Terms: | all |
Description:
Automatic Polymer Preparation System is a comple terange of polymer batching and metering systems.The polymer preparation unit automatically prepares polymer solutions which are used as coagulants for the eventual removal of suspended particles in the water treatment processes of a number of applications from swimming pool maintenance through to the various stages of wastewater treatment, as well as oil recovery, colour removal, paper production and mineral processing.
Polymer dosing device is composed of hopper, push screw, electric heater and etc. The effective volume of the hopper can meet the dosage for a long time which is equipped with sight glasses for observing material level monitored by the dry powder level meter. The push screw driven by the high-precision reducer can satisfy the dosage. The electric heater can be installed in the discharge pipe of push screw, and it can prevent the powder from caking.
Polymer dissolving device Polymer dissolving device is composed of pre-soaking device, tank, and 3 sets of mixers. The pre-soaking device infiltrate and mix the polymer powder in advance. The 3 tanks are precast mixing tank, homogeneous slaking tank and solution storage tank, in which there is a mixer correspond to guarantee the homogeneity.
Applications:
Dosing System is mainly used for the treatment of power plants water supply,boiler water, circulating water and waste water. Also for petroleum, chemical, environmental protection, water supply system and other industries.
Specifications:
Competitive Advantage:
1. Weather protection system ensures the service life of the motor.The whole equipment is made of stainless steel,which is corrosion-resistant and durable.
2. When the pressure drops, it feeds back to the water supplement solenoid valve to supplement water, and at the same time feeds back the signal to the dosing device for automatic dosing
3. Monitor the water level index through the liquid level controller, control the liquid level of the water system between the set values, and ensure the stable operation of the system.
4.The metering pump is installed in a suction type, which is not easy to be blocked, has a long trouble-free running time and low operating costs.
FAQ:
Q1 How to contact and purchase?
A:Please provide the source,characteristic, and flow rate of the target water/wastewater as well as the area.
Q2 How to pay?
A:Both TT and L/C are acceptable and TT is the priority . The deposit 30% and the rest 70% before loading
Q3 What is the delivery time?
A:It depends on the order size generally between 4 to 6 weeks.
Q4 What is the manner of packing?
A:Standard packaging is normally adopted.We will satisfy the special packing requirements as you required, yet the extra cost will be on your side.
Q5 How to protect equipment from corrosion?
A:The anti-corrosion coating process was used with the standard process.
Q6 How to install the equipment?
A: A specification with illustrations will be provided with the equipment. Field installation service is available, yet the cost of visa fees,tickets,accommodation,and wages will be paid by the buyer.
